Millimeter-sized particle sensor

​

CEA-LETI (Commissariat à l'énergie atomique et aux énergies alternatives - Laboratoire d'Electronique et de Technologie de l'Information) has chosen FEMTOprint to realize a Millimeter-sized particle sensor using a wide field of view monolithic lens assembly for light scattering analysis in Fourier domain.

​

CEA's objective within this project was to miniturize optical particulate matter sensors. By illuminating a single particle in an air channel, one can record the light scattering signature with a CMOS image sensor and then classify particles. This signature is optically pre-processed with an advanced, millimeter-sized, monolithic, refracto-reflective optical system. It performs notably a Fourier transform with very wide field of view of scattering angles, and includes as well integrated fluidics and alignment. Functional prototypes were fabricated by FEMTOprint using laser micro machining on glass, selective polishing, and afterwards were replicated with epoxy resin using a molding process.

​

​

​



















Do you want to know more? Read about the testimonial!









                                                                                                                                                                                                     10.08.2020

​
